940
11. Attach the brake and clutch line connector block to the upper yoke and tighten the
new fixing to 9 Nm.
1. Fixing
2. Brake line connector
3. Clutch line connector
12. Connect the electrical connector to the instruments.
13. Fit the cover to as noted for removal and tighten the fixing to 3 Nm.
14. Attach the instruments harness to its retaining clip.
1. Fixing
2. Cover
3. Retaining lug
4. Instruments harness
