946
4. Fit a new seal to the lower end of the headstock with lip of the seal facing the
bearing and is 3 mm past the seat for the bearing outer race.
1. Oil seal
2. Bearing outer race
3. Headstock
4. Lower yoke
5. Evenly and progressively drive the new bearing outer race into the lower end of the
headstock.
6. Fit a new seal to the upper end of the headstock with lip of the seal facing the
bearing and is flush with the seat for the bearing outer race.
1. Oil seal
2. Bearing outer race
3. Headstock
