Triumph Rocket 3 GT 2021 - Page 989

951
4. Release the fixings and detach rear suspension preload adjuster from the battery box.
1. Fixings
2. Preload adjuster
3. Retaining band
4. Rear suspension unit
Part of the main harness is routed near the rear suspension unit upper fixing.
Care must be taken not to damage the harness when removing or installing the rear
suspension unit and its fixings.
NOTICE
Note the position of the harness between the battery box and rear suspension unit
upper fixing for installation.
There is an access hole for access to the rear suspension upper flanged lock nut. It is
located at the lower front right hand corner of the battery box.
