952
5. Remove the flanged lock nut from the upper mounting bolt. Discard the flanged lock
nut.
1. Battery box (rear subframe removed for clarity)
2. Harness
3. Flanged lock nut
4. Engine ECU connectors (2 off)
NOTICE
Note there is a sleeve fitted to the right hand outrigger for the suspension unit upper
mounting bolt.
6. Remove the upper mounting bolt and sleeve.
1. Bolt
2. Sleeve
