2. Remove the sleeve from the right hand drag link bracket.
1. Fixing
2. Drag link brackets
3. Drag link
3. Detach the drag link and remove the sleeve from the lower mounting.
4. Remove the fixing securing the rocker to the swinging arm.
5. Fit service tool T3880209 to the rocker sleeve, fully engaging the threads.
6. Fit service tool T3880208 to service tool T3880209, fully engaging the threads.
1. Sleeve
2. T3880209 – Adaptor
3. T3880208 – Slide Hammer
