Triumph Rocket 3 GT User Manual

Instruments
30
Tachometer
Caution
Never allow engine speed to enter the
red zone as severe engine damage
may result.
The tachometer shows the engine
speed in revolutions per minute - rpm
(r/min). At the end of the tachometer
range there is the red zone.
Engine speeds in the red zone are above
maximum recommended engine speed
and are also above the range for best
performance.
12.4
°
C
0 0 74 82
Trip 1
mi
0
3
1
1. Engine speed (rpm)
The tachometer is shown in the main
circle section of the instrument display
when the Chronos theme is selected.
Fuel Gauge
The fuel gage indicates the amount of
fuel in the tank.
A
15:53
1/3
OK
12.4
°
C
Low Fuel
mi
42.2
mpg RANGE
38
+
N
1 2
3
1. Fuel gage
2. Low fuel warning light
3. Low fuel information tray
The fuel gage is shown in the left hand
panel when the Chronos theme is
selected.
The range to empty and instantaneous
fuel consumption is shown in the right
hand panel when the Fuel menu is
selected.
With the ignition switched on, a filled
line in the fuel gage indicates the fuel
remaining in the fuel tank.
The gage markings indicate
intermediate fuel levels between an
empty and full fuel tank.
The low fuel warning light will illuminate
when approximately 1 gallon (4 liters) of
fuel is remaining in the tank and you
should refuel at the earliest opportunity.

Triumph Rocket 3 GT Specifications

General

Displacement	2458 cc
Max Power	167 PS / 165 bhp (123 kW) @ 6, 000 rpm
Transmission	6-speed
Engine Type	Liquid-cooled, DOHC, inline 3-cylinder
Max Torque	221 Nm @ 4, 000 rpm
Fuel System	Fuel injection
Frame	Aluminum
Front Suspension	Showa 47mm forks, adjustable compression and rebound damping
Rear Suspension	Showa monoshock RSU with piggyback reservoir, adjustable preload, compression and rebound damping
Front Brakes	Brembo M4.30 4-piston radial monobloc calipers, twin 320mm discs
Rear Brakes	Brembo M4.32 4-piston caliper, single 300mm disc
Seat Height	750 mm
Wheelbase	1677 mm
Dry Weight	294 kg
Wet Weight	317 kg
Fuel Capacity	18 liters
