Maintenance and Adjustment
148
Direction Indicator Lights
The motorcycle is fitted with either LED
or bulb direction indicator lights.
LED Direction Indicator Lights
The LED direction indicator light units
are sealed, maintenance free LED units.
The direction indicator light assembly
must be replaced in the event of the
failure of the direction indicator.
Street Scrambler and Street Twin
Direction Indicator Bulb
Replacement
1. Lens
2. Bulb
3. Indicator lens screw
The lens on each indicator light is held
in place by an indicator lens screw
located in the body of the light unit.
To replace the direction indicator light
bulb:
• Release the indicator lens screw and
remove the lens to gain access to
the bulb for replacement.
• Carefully remove the bulb and
replace it with a new bulb.
• Installation is the reverse of the
removal procedure.
Bonneville T100, Bonneville T120,
Bonneville T120 Ace and
Thruxton RS Direction Indicator
Bulb Replacement
3
21
1. Bulb
2. Locating tangs
3. Lens
To replace the direction indicator light
bulb:
• Carefully twist the lens anti-
clockwise and remove from the
indicator to gain access to the bulb.
• Gently press the bulb inwards and
twist anticlockwise. Replace with a
new bulb.
• Installation for the bulb is the
reverse of the removal procedure.
Caution
When installing the lens, make sure
that the locating tangs are correctly
aligned to the indicator body.
• To install the indicator lens, align
the locating tangs with the indicator
body and twist anticlockwise to
secure.
