CV Discription DCC Value
1 Adress 1 – 127
3 Acceleration delay 0 – 127
4 Braking delay 0 – 127
5 Maximum speed 1 – 7
17 Extended address (Upper part) CV 29 bit 5 = 1
18 Extended address (Lower part) CV 29 bit 5 = 1
Value
29 bit 0: Travel direction polarity reversal 0/1
***
bit 1: number of speed levels 28/128 0/2 0, 1, 2, 3, 4, 5,
bit 2: DCC Operation with braking Block. 6, 7, 32, 34, 35,
DCC-, Selectrix- and DC power Operation 0/ 4 36, 37, 38, 39
bit 5: Address size 7 bit /14 bit 0/32
49 Pulse width for motor control 0 – 3
50 Rule variant 0 – 3
51 bit 0: Motor polarity reversal 0/1 0 – 7
bit 1: Headlight polarity reversing 0/2
bit 2: Track polarity reversal 0/4
*
*
*
*
*
Important: Changes in the settings market with ( ) for the Selectrix
mode of operation automatically lead to changes in the DCC mode
of operation and versa!
*
The values for the desired settings must be added.
***
