08
Fan F1: There are 4 modes for the F1 fan with separate settings for Day and
Night. These 4 modes include:
• Cool only mode: The exhaust fan is solely controlled by the temperature in the
grow tent
• Dehu only mode: The exhaust fan is solely controlled by the humidity levels in
the grow tent
• Cool priority mode: The exhaust fan is controlled by both temperature and
humidity, however, it will prioritize temperature to be within the defined range if
both can’ t be achieved.
• Dehu Priority mode: The exhaust fan is controlled by both temperature and
humidity, however, it will prioritize humidity to be within the defined range if both
can’ t be achieved.
Within the F1 setting page, you can also set the minimum and maximum
fan speed the exhaust fan can operate at. When using only a single Exhaust fan,
EC Fan Settings
The Devices tab is where you will set up your climate control devices. With the
use of our plug-in DS modules, you can connect and control the devices via the
controller. TrolMaster’ s Tent-X can control multiple device modules.
When you open the Devices page, there you can select what each of your connect
device modules will be controlling. You have 2 device slots available each for
temperature T1 & T2, humidity H1 & H2, and CO2 C1 & C2. You can also set 4 programmable timer devices,
labeled from P1 to P4.
Move the cursor to the device module setting you want to change. Press ENTER to access the device's
settings. You can then use the UP or DOWN arrows to select what kind of device is connected to the Tent-X.
When you have finished selecting the device you’ ve connected for each device module, press ENTER again
to confirm the selections.
The program device modules can be used to connect either more climate devices or timer-based irrigation
devices like solenoids and pumps. If you want to connect irrigation devices to set up irrigation schedules,
you can use the DSP1 or 2 modules (120 or 240v), or the DSV-1 (12-24v AC/DC), to set up your preferred
schedules. In order to program a device by schedule, press ENTER on any of the program tabs from P1 to
P4. The LCD screen will then display 3 options, where you can set what kind of schedule you’ d like to set. If
you choose the single schedule setting, there are only 2 timers you will have to set. You simply input when
you want the device to turn on, and when it turns off. If you choose the multi-schedule setting, you can set
up to 12 individual On and Off times for each device to follow within a 24-hour “day” . If you choose to use
the recycle timer mode, you will be able to determine the On and Off time duration, and the recycle timer mode
will then repeat that same On / Off duration schedule as many times as you’ d like, working as a
repeat-cycle timer. You will also be able to select the time of day for the repeat-cycle to begin, as well as be
able to determine how many cycles will be repeated before the timers are shut off until the next day. The
Tent-X controller will handle the rest once you've set up your preferred irrigation schedule. Your timer-controlled
devices will be controlled automatically with the TCS-1 according to the settings you specified.
Devices
Devices Setting
T1
Heat
T2
Cool
H2
Dehumid
C2
Out
H1
Humid
C1
In
P1 P3P2 P4
Setting
Setting
Day & Night
Climate
Light
EC Fan
Devices
System
Setting
2
Humid
Temp
2
Setting
Exhaust Fan
(F1)
Intake Fan
(F2)
To Next Page
