TrolMaster Tent-X - Understanding The Menu; Pages; TCS-1 Setting Pages

07
There are 4 Main menu pages on the TCS-1. When you first power on the controller, the Home page will be
shown. On that page you can see the current environmental conditions inside the tent. Pressing the right
arrow button will bring you to the current irrigation conditions. You can also use the left arrow button to
view the Device status and the Alarm messages pages. The Device status page will show the current status
(On / Off) of each device connected to the TCS-1. The Alarm page will show the most recent alarm
messages.
Understanding The Menu / Pages
From the main menu on the TCS-1, when you press ENTER on the Tent-X, you will
enter a Setting page consisting of five blocks, with each block accessing a
specific page with settings for Climate settings, Lights, Devices, EC fans and
System settings.
TCS-1 Setting Pages
After pressing ENTER on the Day&Night Climate tab, you will open the page where
you can set the temperature, humidity, and CO2 levels in the grow tent for both
day and night. After the climate parameters have been set, the climate devices
connected to the Tent-X will automatically maintain those settings.
Day&Night Climate
After pressing ENTER on the Light block, the screen will display Line 1 and Line 2.
Use the UP and DOWN arrows to choose Line 1 or Line 2 and press ENTER to
navigate to the page where you can make changes to the selected Line.
On this page, you can create your light settings. Use the UP and DOWN buttons to
navigate the options on this page and press ENTER on an item to change it. When
you see the item blinking, you can switch between the selections using the UP
and DOWN arrows. When you have selected your item, press ENTER again to
confirm the selection. Select whether you’ re using HID or LED lights. You can
also select the On/Off time for your lights, the temperature at which the lights will
dim, the Sunrise and Sunset time, and more.
Lights
Setting
2
Humid
Temp
2
Setting
Day & Night
Climate
Light
EC Fan
Device
System
65
50
70
55
1200
400
ppm
o
F
Temp Humid CO2
o
F %
%
ppm
Night Setpoint
Day Setpoint
Temp Humid CO2
Setting
Lighting
Line 1
Line 2
Setting
Line 1 Lighting
Mode LED
08:00
100%
84
o
F
20:00
89
o
F
OFF
Power
On at
Off at
Dim at
Stop at
Sun R/S time
