TRONIC TLGL 1000 A1
4 - English
Technical specifications
Input voltage 100 to 240 V
~
, 50/60 Hz
Power consumption 30 W
Safety Class II
Operating temperature +5 °C to +35 °C
Storage temperature -10 °C to +40 °C
Relative humidity max. 85% rel. humidity (non-condensing)
Output voltages 1.2 V (AA, AAA, C and D types)
4.2 V (Li-Ion: 3.6 V / 3.7 V)
Charging current 6 x 1000 mA (AA type)
6 x 500 mA (AAA type)
4 x 1000 mA (C and D types)
1 x 500 mA (Li-Ion: 3.6 V / 3.7 V)
Only suitable for charging the
following battery cells
NiMH (1.2V x 1 to 6 cells AAA, max. 1500mAh/cell)
NiCd (1.2V x 1 to 6 cells AAA, max. 1500mAh/cell)
NiMH (1.2V x 1 to 6 cells AA, max. 3000mAh/cell)
NiCd (1.2V x 1 to 6 cells AA, max. 3000mAh/cell)
NiMH (1.2V x 1 to 4 cells C, max. 6000mAh/cell)
NiCd (1.2V x 1 to 4 cells D, max. 9000mAh/cell)
Li-Ion (3.6V/3.7V x 1 cell, max. 3000mAh/cell)
USB output 5 V , 1000 mA
Dimensions (W x H x D) approx. 220 x 46 x 155 mm
Weight approx. 600 g
Safety tested
The technical specifications and design can be changed without prior notice.
Safety instructions
Before you use the charger for the first time, please read the following notes and heed all warnings,
even if you are familiar with handling electronic devices. Keep these operating instructions in a safe
place for future reference. If you sell the charger or give it away, pass on the operating instructions
at the same time.
