9 EN
Operating manual – cordless multi-function tool PMTS 10-20V
Start-up
Unpacking the device
• Take the transport case out of the packaging.
Warning of electrical voltage
Electric shock from insufficient insulation.
Check the device for damages and proper functioning
before each use.
If you notice damages, no longer use the device.
Do not use the device when the device or your hands
are damp or wet!
• Check the contents of the transport case for completeness
and look for damages.
Warning
Risk of suffocation!
Do not leave the packaging lying around. Children may
use it as a dangerous toy.
• Dispose of the packaging material according to the
national regulations.
Charging the battery
Notice
The battery can be damaged in case of improper
charging.
Remove the charger's mains plug before inserting or
removing the battery.
Never charge the battery at ambient temperatures
below 10°C or above 40°C.
The battery is partially charged upon delivery to avoid damage
to the battery caused by a deep discharge.
Prior to initial start-up and when the battery is low (only the red
LED in the battery level indication(8a) is illuminated), the
battery should be charged. To do so, please proceed as follows:
1. Insert the battery(8) into the quick charger(11) upside
down.
2. Insert the mains plug of the quick charger(11) into a
properly fused mains socket.
ð The red battery LED(17) lights up.
ð Charging requires approx. one hour.
3. Wait until the red battery LED(17) goes off and the green
battery LED(16) lights up.
ð The battery(8) is fully charged.
4. Hold onto the mains plug while pulling the power cable of
the quick charger(11) out of the mains socket.
ð The battery(8) and the quick charger(11) may have
become warm during charging.
Allow the battery(8) to cool down to room temperature.
5. Remove the battery(8) from the quick charger(11).
Inserting the battery
1. Slide the battery(8) onto the device until it locks in place.
