Trotec PSCS 11-3,6V User Manual

EN 10
cordless screwdriver with bit magazine PSCS 11-3,6V
Filling the bit magazine
You can fill the bit magazine with up to 6bits (25mm).
1. Set the switch for clockwise/counter-clockwise rotation(5)
to centre position(lock).
2. Pull the slide switch for bit exchange(3) forward.
ð The current bit is pushed into the bit magazine(12).
3
12
2
3. Remove the bit magazine(12) from the device by pushing
the bit magazine out to the left.
12
14
4. Take the bit magazine(12) off the holder(14).
5. Remove bits which are no longer needed from the bit
magazine(12).
6. Fill the desired bits into the bit magazine(12). Make sure
that the bit tips point to the front.
7. Place the bit magazine(12) back on the holder(14). The bit
magazine(12) has a thicker edge at the front so that it can
only be placed on in one direction.
8. Push the bit magazine(12) back into the device.
9. Select a bit if required.
10. Pull the slide switch for bit exchange(3) back.
ð The current bit is pushed out of the bit magazine(12)
into the magnetic bit holder(1).

Trotec PSCS 11-3,6V Specifications

General

Brand	Trotec
Model	PSCS 11-3, 6V
Category	Power Screwdriver
Language	English
