table fan TVE 8 / TVE 9
Maintenance
Activities required before starting maintenance
Warning of electrical voltage
Do not touch the mains plug with wet or damp hands.
• Switch the device off.
• Hold onto the mains plug while pulling the power cable out
of the mains socket.
Cleaning the housing
Clean the housing with a soft, damp and lint-free cloth. Make
sure that no moisture enters the housing. Protect electrical
components from moisture. Do not use any aggressive cleaning
agents such as cleaning sprays, solvents, alcohol-based or
abrasive cleaners to dampen the cloth.
• Other than that, the device does not require maintenance.
Technical annex
Technical data
Parameter Value
Model TVE 8 / 9
Fan stages 2
Air flow rate 555.6 m
3
/h
Air velocity 1.48 m/s
Input voltage 230 V / 50 Hz
Power consumption 25W
Power cable length 1.50 m
Adjustable inclination angle 30°
Oscillation function 90°
Fan blade diameter 23 cm
Sound pressure level
(at a distance of 1m)
56.5 dB(A), level 2
Dimensions
(lengthx widthx height)
210 x 270x 370mm
Minimum distance to walls and
other objects:
top (A):
rear (B):
sides (C):
front (D):
20 cm
20 cm
20 cm
20 cm
Weight 1.1kg
