6 EN
submerged waste water pump TWP 4036 E / TWP 7536 E / TWP 9000 ES / TWP 11000 ES
Device depiction
TWP 4036 E / TWP 7536 E
1
3
4
2
6
5
TWP 9000 ES / TWP 11000 ES
1
2
5
6
4
3
Accessories
7
8
a
b
c
d
No. Designation
1 Transport handle / attachment for nylon cord
2 Connection for connection system
3 Float switch locking device
4 Float switch
5 Power cable
6 Air intake opening (with cover panel)
7 Reducer
8 Elbow
Connection options
No. Designation
a Hose connection for an inner diameter of 25mm
(with hose clamp)
b Hose connection for a G1"/ DN25 internal thread
c Hose connection for an inner diameter of 38mm
(with hose clamp)
d Hose connection for a G1½"/ DN40 internal thread
