Ref. Part No. Description
1 687-02022 Curb Height Adjustment Lever
2 687-02125A Curb Height Adjuster Plate
3 687-02126 Blade Plate Assembly
4 710-0191 Screw ⁄-24
5 710-0411 Screw ⁄-16
6 710-04389 Hex Screw, ⁄-18
7 710-0599 Self-tapping Screw, ⁄-20
8 710-0654A Screw, ⁄-16
9 710-0726 Hex Screw, ⁄-12
10 710-0870 Hex Screw ⁄-18
11 710-1143A Hex Screw, ⁄-18
12 710-1174 Carriage Bolt, ⁄-18
13 710-1205 Rope Guide (Eye Bolt)
14 710-3180 Hex Screw, ⁄-18
15 711-04361 Axle Shaft .50x6.65
16 711-04440 Frame Spacer .50x9.25
17 712-04063 Lock Flange Nut, ⁄-18
18 712-04065 Flange Nut ⁄-16
19 712-0417A Flange Nut, ⁄-18
20 714-3010 Clevis Pin ⁄ x .625
21 718-04012 Bearing Cup
22 720-0142 Grip
23 720-0279 Wing Nut
24 720-04072 Star Knob
25 726-0299 Push Cap ⁄” rod
26 731-04207 Bearing Block
27 731-05063 Debris Guard
28 731-05064 Blade Guard
29 732-0188A Double Torsion Spring
30 732-0369 Compression Spring
31 732-04045 Torsion Spring
32 732-04169 Compression Spring
33 734-1264 Wheel 7 x 1.75 T-Tread
Ref. Part No. Description
34 734-1268 Wheel 8 x 1.75 T-Tread
35 736-0179 Flat Washer ⁄ x 1.25 x .10
36 736-0232 Wave Washer .531 x .781 x .013
37 736-0234 Flat Washer, .385 x 1.5 x .075
38 736-0258 Flat Washer .385 x 1.0 x .135 †
39 736-04088 Flat Washer .635x1.24x.181
40 736-0452 Bell Washer,.396 x 1.140
41 738-04149 Shoulder Screw, ⁄-16
42 738-0706C Shoulder Screw
43 738-0929 Shoulder Screw, ⁄-16
44 741-0524 Bearing, .625 ID x 1.57 OD
45 746-04035 Control Cable (Briggs & Stratton)
46 746-04036 Wheel Adjustment Cable
47 747-04110 Blade Adjustment Rod
48 747-0976A Bail Handle
49 749-04183 Upper Handle
50 749-04234 Lower Handle
51 750-04105 Spacer, .63 x 1.12 x 1.06
52 750-04129 Spacer
53 750-04142 Pulley Mount Spacer
54 750-0547 Spacer, .64 x.88 x .50
55 754-04032B Belt
56 756-04148 Flat Idler Pulley, 2.5 OD
57 756-0449 Sheave
58 756-1150A Combination Flywheel Pulley
59 781-0427 Belt Guard
60 781-0741A Depth Index Bracket
61 781-0742 Depth Index Lever
62A 781-0748 Tri-Star Blade
62B 781-0080 Edger Blade
63 787-01081A Bracket Plate
64 787-01239 Dual Wheel Bracket
65 787-01304 Frame
17
Handle, Frame & Wheel Assembly
