TROY-BILT LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019
Printed In USA
Op e r a t O r ’s Ma n u a l
Safe Operation Practices • Set-Up • Operation • Maintenance • Service • Troubleshooting • Warranty
WARNING
READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL
BEFORE ATTEMPTING TO OPERATE THIS MACHINE.
FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY.
Self Propelled Mower — Models TB330 XP/ TB350 XP
Form No. 769-06390
(December 20, 2010)

Table of Contents

Questions and Answers

  • H
    Hector ThomasAug 15, 2025
    How to fix Troy-Bilt TB330 when engine fails to start?
    • M
      marissasimsAug 15, 2025
      If your Troy-Bilt Lawn Mower engine won't start, make sure the blade control is engaged. Check that the spark plug boot is connected. If the fuel tank is empty or the fuel is stale, fill it with clean, fresh gasoline. If equipped with a primer, prime the engine as instructed. Inspect the spark plug; clean, adjust the gap, or replace it if necessary. Also, ensure the fuel line is not blocked and, if the engine is flooded, wait a few minutes before restarting without priming. If your mower has a fuel valve, ensure it's open, and if equipped with a choke, use it to choke the engine. Finally, for electric start models, check and replace the fuse if it's burnt.
  • B
    Brandy StarkAug 19, 2025
    Why does my Troy-Bilt TB330 engine run erratic?
    • H
      harrisbrandiAug 19, 2025
      If your Troy-Bilt Lawn Mower engine runs erratically, start by checking the spark plug boot and ensure it's connected and tight. Clean the fuel line and fill the tank with fresh gasoline if it's blocked or the fuel is stale. Also, clear the vent in the gas cap and drain the fuel tank to refill with fresh fuel if there's water or dirt in the system. If your unit is running with the choke applied, push the choke knob in.
  • B
    Brian PhamAug 21, 2025
    What to do if Troy-Bilt Lawn Mower will not mulch grass?
    • W
      Wanda JohnsonAug 21, 2025
      If your Troy-Bilt Lawn Mower is not mulching grass effectively, it could be due to several reasons. Avoid mowing when the grass is wet, as this reduces mulching efficiency. If the grass is excessively high, mow once at a higher setting and then again at your desired height, or narrow the cutting path. A dull blade will also hinder mulching, so sharpen or replace it to improve performance.
  • C
    caseycatherineAug 25, 2025
    Why is my Troy-Bilt TB330 engine overheating?
    • A
      Angelica GutierrezAug 26, 2025
      If your Troy-Bilt Lawn Mower engine overheats, check the engine oil level and fill the crankcase with the proper oil if it's low. Also, ensure that the airflow around and on top of the engine is not restricted by cleaning the area.
  • W
    williamssamuelAug 27, 2025
    How to fix uneven cut with Troy-Bilt TB330 Lawn Mower?
    • S
      shawn38Aug 28, 2025
      If your Troy-Bilt Lawn Mower provides an uneven cut, the most likely cause is a dull blade. Sharpen or replace the blade to ensure a clean, even cut.
  • C
    cabrerachristyAug 30, 2025
    Why does my Troy-Bilt TB330 have excessive vibration?
    • K
      Kristine KramerAug 30, 2025
      If your Troy-Bilt Lawn Mower is experiencing excessive vibration, it may be due to a loose or unbalanced cutting blade. Tighten the blade and adapter, and balance the blade. If the cutting blade is bent, consult an authorized service dealer for assistance.
  • M
    Melissa Logan DVMSep 2, 2025
    What to do if Troy-Bilt Lawn Mower will not self propel?
    • C
      christophersmithSep 3, 2025
      If your Troy-Bilt Lawn Mower will not self-propel, check the belt for proper pulley installation and movement. If there is debris clogging the drive operation, stop the engine, disconnect the spark plug boot, and clean out the debris. Inspect and replace the belt if it is damaged or worn. If the drive control is out of adjustment, adjust it.
  • R
    Robin WilliamsSep 6, 2025
    Why does my Troy-Bilt Lawn Mower skip at high speed?
    • C
      Clayton MartinezSep 6, 2025
      If your Troy-Bilt Lawn Mower occasionally skips or hesitates at high speed, the spark plug gap may be too close. Adjust the gap to .030 inches.
  • P
    Patricia SalazarSep 8, 2025
    Why does my Troy-Bilt TB330 idle poorly?
    • L
      Laura WrightSep 8, 2025
      If your Troy-Bilt Lawn Mower idles poorly, the spark plug may be fouled, faulty, or have a gap that is too wide. Reset the gap to .030 inches or replace the spark plug.
  • E
    Erica HudsonSep 12, 2025
    Why is there high pullback effort on my Troy-Bilt TB330?
    • W
      William MirandaSep 12, 2025
      If you experience high pullback effort with your Troy-Bilt Lawn Mower, allow the unit to roll forward slightly without the drive lever(s) engaged before pulling backwards. This allows the transmission to disengage.

Summary

Important Safe Operation Practices

Slope Operation Safety

Guidelines and warnings for operating the mower on slopes.

Child Safety Precautions

Specific warnings and rules regarding children around the mower.

Safety Symbol Explanations

Descriptions and meanings of various safety symbols used in the manual.

Assembly & Set-Up

Drive Control and Handle Pitch

Adjusting drive control tension and setting the handle pitch.

Gas and Oil Fill-Up

Procedure for adding fuel and oil before initial operation.

Controls and Features

Key Control Levers and Indicators

Overview of blade control, drive controls, speed control, and height lever.

Operation

Starting and Stopping Engine

Procedures for safely starting and stopping the mower's engine.

Mowing Procedures

Maintenance & Adjustments

Deck Cleaning and Care

Engine Care Procedures

Service

Safe Gasoline Handling

Precautions for safely handling gasoline and preventing fires.

Engine Modification Warning

Blade and Belt Care

Troubleshooting

Engine Starting and Running Problems

Common issues with engine starting, erratic running, and overheating.

Performance and Vibration Issues

Mowing and Propulsion Problems

Replacement Parts

Troy-Bilt TB330 Specifications

General IconGeneral
Cutting Width21 inches
Cutting Height1.25-3.75 inches
Drive TypeSelf-propelled
Starter TypeRecoil
Deck MaterialSteel
Drive SystemRear-Wheel Drive
Rear-Wheel DriveYes
Mulch CapableYes
Side DischargeYes
Rear BagYes
Washout PortYes
Cutting Positions6
Speed SettingsVariable
Warranty2-year limited
Engine TypeGasoline
Cutting Height AdjustmentSingle-lever
