E23
PARTS LIST
Item Part No. Description
1 753-04234 Throttle Housing Assembly (includes 2-4)
2 791-182405 Switch
3 753-04119 Throttle Trigger
4 791-182690 Throttle Trigger Spring
5 753-04405 Throttle Cable
6 791-610327 Harness Clip
7 753-04880 Drive Shaft Housing Assembly
8 791-153064 D-Handle (includes 9)
9 791-153317 D-Handle Hardware Assembly
10 753-04832 Flexible Drive Shaft
11 791-153597 Lower Clamp Assembly (includes 13)
12 791-180547 Guard Mounting Screw Assembly
13 791-180548 Guard and Blade Assembly
14 791-180553 Blade Assembly
15 791-145569 Anti-Rotation Screw
16 791-180549 Gearbox Assembly (includes 15 & 16)
17 791-153619 Outer Spool Assembly
18 791-610660 Retainer (10 pack)
19 791-610317B Spring
20 753-1155 Inner Reel
21 791-153066B Bump Head Knob Assembly
Optional
Accessories
* 791-153577B Spool and Line (25 ft.) Assembly
* Items Not Shown
1
1
3
4
5
8
9
10
11
13
14
15
16
14
12
17
18
19
20
21
2
1
6
7
BOOM AND TRIMMER PARTS - TB65SS
2-CYCLE GAS TRIMMER
