True FORCE - Assembly Steps

CHAPTER 2: ASSEMBLY GUIDE
Truefitness.com / 800.426.6570 / 636.272.7100 7
UNIT ASSEMBLY STEPS:
STEP 1 Brace Frame:
1. Attach the Brace Frame to the Main Frame as
shown below.
ITEM
Description
Qty
11
M10x80 Socket Head Cap Screw
2
15
Flat Washer 11x20x2
4
16
Nylon Lock Nut M10
2
Main Frame
11
15
15
16
Brace Frame
