CHAPTER 2: ASSEMBLY GUIDE
Truefitness.com / 800.426.6570 / 636.272.7100 9
UNIT ASSEMBLY STEPS (continued):
STEP 3 Angled Bracket & Seat Pad Support:
1. Attach the Angled Bracket and Seat
Pad Support as shown below.
ITEM
Description
Qty
13
M10x25 Flat Head Cap Screw
4
15
Flat Washer 11x20x2
4
16
M10 Nylon Lock Nut M10
4
Main Frame
13
16
15
Angled Bracket
Seat Pad Support
16
15
13
