18
STEP 1—ATTACH MAIN FRAME ASSEMBLY TO UPRIGHT ASSEMBLY CONTINUED
1
3
2
4
6
5
4
b. Align the main frame assembly with the upright assembly. Using an allen wrench, attach the main frame assembly to
the upright assembly using the 6 hex screws, 6 lock washers, and 4 fl at washers you removed previously.
NOTE: To help align parts, loosely attach all screws before fully tightening.
To Next Page
