STEP 3—ATTACH WEIGHT STACK TO UPRIGHT ASSEMBLY CONTINUED
7
4
h. Insert the hex screw through the lock washer, fl at washer, and selector pin attachment point and reattach it to the
Generation 1 top weight assembly using an allen wrench. Insert the hex screw through the lock washer, fl at washer,
and selector pin attachment and reattach it to the Generation 2 top weight assembly using an allen wrench.
i. Using a degreaser and cloth, remove oil from the weight plates that was applied for anti corrosion during the
manufacturing process.
13
14
7
15
13
14
7
15
Generation
1
Generation
2
