STANDARD FEATURES
Model:
TRUE FOOD SERVICE EQUIPMENT
St. Charles Industrial Center • P.O. Box 970 • O’Fallon, Missouri 63366 • (636)240-2400 • FAX (636)272-2408 • (800)325-6152 • www.truemfg.com
WARRANTY
One year warranty on all parts
& labor and an additional 4 year
warranty on compressor.
(U.S.A. only)
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
Model Elevation Right Plan 3D
PLAN VIEW
KCL
1
3
/8"
(35 mm)
T-49F TFEY02E TFEY02S TFEY02P TFEY023
T-49F
DESIGN
• True’s solid door reach-in’s are designed
with enduring quality that protects your
long term investment.
• True’s commitment to using the
highest quality materials and oversized
refrigeration systems provides the user
with colder product temperatures, lower
utility costs, exceptional food safety and
the best value in today’s food service
marketplace.
REFRIGERATION SYSTEM
• Factory engineered, self-contained,
capillary tube system using environmentally
friendly (CFC free) R404A refrigerant.
• Extra large evaporator coil balanced with
higher horsepower compressor and large
condenser maintains -10°F (-23.3°C). Ideally
suited for both frozen foods and ice cream.
• Sealed, cast iron, self-lubricating
evaporator fan motors and larger fan
blades give True reach-in’s a more
effi cient low velocity, high volume airfl ow
design. This unique design insures
faster temperature recovery and shorter
run times in the busiest of food service
environments.
• Bottom mounted condensing unit
positioned for easy cleaning. Compressor
runs in coolest and most grease free area
of the kitchen. Allows for storage area on
top of unit.
• Automatic defrost system time-initiated,
temperature-terminated. Saves energy
consumption and provides shortest possible
defrost cycle.
CABINET CONSTRUCTION
• Exterior - 300 series stainless steel front grill
and shroud. Anodized quality aluminum
exterior ends, back and top.
• Interior - attractive, NSF approved, white
aluminum liner. 300 series stainless fl oor
with coved corners.
• Insulation - entire cabinet structure and
solid doors are foamed-in-place using high
density, CFC free, polyurethane insulation.
• Welded, heavy duty galvanized frame rail
dipped in rust inhibiting enamel paint for
corrosion protection inside and out.
• Frame rail fi tted with 4" (102 mm)
diameter stem castors - locks provided on
front set.
DOORS
• 300 series stainless steel exterior with white
aluminum door liners to match cabinet
interior. Doors extend full width of cabinet
shell. Door locks standard.
• Positive seal self-closing doors. Lifetime
guaranteed door hinges and torsion type
closure system.
• Lifetime guaranteed recessed door handles.
Each door fi tted with 12" (305 mm) long
recessed handle that is foamed-in-place
with a sheet metal interlock to insure
permanent attachment.
• Magnetic door gaskets of one piece
construction, removable without tools for
ease of cleaning.
SHELVING
• Six (6) adjustable, heavy duty PVC coated
wire shelves 24
9
/16"L x 22
3
/8"D
(624 mm x 569 mm). Four (4) chrome
plated shelf clips included per shelf.
• Shelf support pilasters made of same
material as cabinet interior; shelves are
adjustable on
1
/2" (13 mm) increments.
LIGHTING
• Incandescent interior lighting - safety
shielded. Lights activated by rocker switch
mounted above doors.
MODEL FEATURES
• Exterior mounted temperature monitor.
• Evaporator is epoxy coated to eliminate
the potential of corrosion.
• Rear airfl ow guards prevent product from
blocking optimal airfl ow.
• NSF-7 compliant for open food product.
ELECTRICAL
• Unit completely pre-wired at factory and
ready for fi nal connection to a 115/60/1
phase - 20 amp dedicated outlet. Cord and
plug set included.
OPTIONAL FEATURES/ACCESSORIES
Upcharge and lead times may apply.
❒ 230 - 240V / 50 Hz.
❒ 6" (153 mm) standard legs.
❒ 6" (153 mm) seismic/fl anged legs.
❒ Alternate door hinging (factory installed).
❒ Additional shelves.
❒ Half door bun tray racks. Each holds up
to eleven 18"L x 26"D (458 mm x 661 mm)
sheet pans (sold separately) (airfl ow guards
need to be removed).
❒ Full door bun tray racks. Each holds up to
twenty-two 18"L x 26"D (458 mm x 661
mm) sheet pans (sold separately) (airfl ow
guards need to be removed).
❒ Remote cabinet and/or condensing
unit. System comes standard with 404A
expansion valve and requires R404A
refrigerant.
ELEVATION
PLAN VIEW
115/60/1
NEMA-5-20R
T Series:
Reach-In Solid Door Freezer
5"
(127 mm)
76
15
/16"
(1955 mm)
78
5
/16"
(1990 mm)
54
1
/8"
(1375 mm)
83
5
/16"
(2117 mm)
25
17
/32"
(649 mm)
29
1
/2"
(750 mm)
55
1
/32"
(1398 mm)
