True TUR-24-R/L-SS-B User Manual

8
TRUE RESIDENTIAL LINE
INSTALLATION SPECIFICATIONS - STAINLESS SOLID & GLASS DOOR
True’s Stainless Solid and Glass Door units are designed to be inserted into a cabinet opening or free standing.
Below are recommended dimensions for rough opening.
True’s stainless steel cabinets are UL rated for use in outdoor settings.
In outdoor locations where the ambient temperature regularly exceeds 95˚F, it is recommended to vent the rear
of the cut out opening in the area shown below for optimum performance.
The recommended cut out size is 4” x 10”.
23
7
/
8
"
29
3
/
4
"
4
1
/
8
"
Rough Opening
HEIGHT
34
1/2
”
Front view
of unit
between
cabinets
Rough Opening
DEPTH
24”
Rough Opening
WIDTH
24”
24 INCH
Rough
Opening
HEIGHT
34
1/2
”
Rough
Opening
DEPTH
24”
Front
view of
unit
between
cabinets
Rough
Opening
WIDTH
15”
15 INCH

True TUR-24-R/L-SS-B Specifications

General

Brand	True
Model	TUR-24-R/L-SS-B
Category	Refrigerator
Language	English
