Dimensions, Abmessungen, Dimensiones, Dimensioni
48mm
(1.89")
48mm (1.89")
93mm (3.66")
76mm (2.99")
3mm (0.12")
5mm (0.2")
1234567
8
9
10
11
12 13 14
45 x 45mm
+0.6mm -0mm
(1.77" x 1.77"
+0.024" -0")
8.5mm
(0.335")
4.5mm
(0.177")
Ø 4.3mm (0.17")
60mm (2.36")
63mm
(2.48")
75mm
(2.95")
=<12mm
(0.48")
Screw-fixed bezel, Frontrahmen mit
Schraubenbefestigung, Cadre à vis,
Marco fijado con tornillos, Cornice a vite
Fixing Clip, Befestigungs-klammer,
Clip de fixation, Clip fijación,
Fermaglio di fissaggio
