TSC KP-200 Plus Service Manual

4
(3) Keyboard COM1 and COM2 pin assignment
KEYBOARD COM1 KEYBOARD COM2
Pin
Configuration
Pin
Configuration
1
Power input 5 volts,
250mA
1
Power input 5 volts,
250mA
2 RxD 2 TxD
3
TxD
3
RxD
4 Not used 4 Not used
5
Ground
5
Ground
6 Not used 6 Not used
7
Not used
7
Not used
8 Not used 8 Not used
9
Connect with Pin1
internally
9
Not used
(Short JP4: Connect with
Pin1 internally)
Note: (1) Be sure to connect well the scanner and keyboard before turn on the
printer power
(2) Please disable the CTS/RTS and Xon/Xoff handshaking of the scanner.
(3) The postfix 0Dh and 0Ah should be set in scanner.
 The information contained herein is subject to change without notice.
 Reproduction of this manual either in part of its entireties is forbidden.
 Note that the manufacturer assumes no responsibility for any injury or
loss incurred while using this manual.
