Parts List

Item No.

Part No. Description Remark

Spare

Parts

1 30-0170003-00LF Upper Cover

2 30-0170004-00LF Lower Cover

3 36-0170002-10LF Keypad

As shown in Page 2,

the Outline section

4 37-1403006-34LF Tap Screw 3*6 2 pcs (MOQ 50 pcs)

5 37-1403008-34LF Tap Screw 3*8 4 pcs (MOQ 50 pcs)

6 98-0170200-00LF Main PCB Ass'y

7 66-2002011-10LF LCD module

8 72-0040011-00LF COM1 Cable Connector JP1

9 30-0170005-40LF Keyboard membrane
