Chapter 3
8
Figure 3-1
3. Use mild soap and warm water to clean the jet assembly parts. Examine
the orifice for plugging. Rinse a second time if necessary. Either use
clean compressed air to dry the parts, or air dry them.
Note: The orifice is easily damaged. Do not insert anything in the orifice
in an attempt to clean it.
4. Reassemble and install the atomizer jet, making sure you replace the
O-rings. When you replace the retainer, make sure it is pushed in
completely.
5. Attach the draw tube.
6. Test the generator for proper operation (output) using tap water.
Retainer
1
3
4
5
2
