ARIA 240 & 240 SUPER
OPERATING MANUAL V01
TSM - Technological Systems by Moro Srl
Via F.lli Zambon,9 - 33080 Fiume Veneto (PN) Italy
Tel. +39.0434.564167 - Fax +39.0434.954069
www.tsmitaly.com sales@tsmitaly.com
3
COMPONENTI MACCHINA - VERSIONE 240 & 240 SUPER
CONTROLLI E STRUMENTI - VERSIONE 240 & 240 SUPER
Consolle Maniglia-joystick di controllo
1
Timone di controllo
7
Compartimento filtro cartuccia
2
Tubo di aspirazione
8
Lampeggiante
3
Maniglia-joystick di controllo
9
Estintore
4
Ruote trazione posteriori
10
Supporto tubo di aspirazione (solo per 240 Super)
5
Tanica acqua
11
Termiche di protezione
6
Contenitore rifiuti
1
Chiave avviamento
7
-
2
Regolatore di velocità
8
Fungo emergenza
3
Contaore / Indicatore di carica batterie
9
Azionamento controllo min/max motore aspirazione
4
Azionamento motore aspirazione
10
Azionamento nebulizzatore
5
Azionamento fanali (optional)
11
Clacson
6
Azionamento sistema pulizia filtro (solo per 240 Super)
1
2
5
6
7
3
9
8
4
9
4
5
6
7
8
3
2
1
9
10
10
1
2
3
5
4
6
7
8
11
