7 – English
EN
02. Wait for the changes to be confirmed by the leds flashing alternately.
03. Turn the “Wind” trimmer to the desired setting.
04. Wait for the changes to be confirmed by the leds flashing alternately.
DIAGNOSTICS
7
You can enable “DIAGNOSTICS mode” at any time to check whether the weather con-
ditions at the time are above or below the setpoint.
To enable diagnostics, press “P1” briefly (< 2 seconds). Now watch the Led and check
the sequences of flashes against Table A.
Note – If several thresholds are exceeded during normal operation (for example, both
the sun and wind thresholds), the diagnostics signals only the one which has the lower
number in Table A.
Caution! – Diagnostics mode can only be used for reading signals off
the Leds, not for operating the awning.
Table A - Led diagnostics signals
1
Red Led flashing (3 short flashes) =
The wind setpoint has been exceeded
2
Green Led flashing (3 short flashes) =
The sun setpoint has been exceeded
(TGWS only – not available on TGW)
3
Led green and red led flashing alternately =
No setpoint exceeded
BASIC TROUBLESHOOTING
8
If the wind or sunlight are stronger than their respective trip values
but the motor does not respond as it should, check that the sensor is pow-
ered correctly and memorized in the motor’s receiver (see chapters 3 and 4). If this does
not solve the problem, check the operation of the sensor by running the diagnostics de-
scribed in chapter 7.
PRODUCT DISPOSAL
9
This product is an integral part of the automation and must therefore be scrapped togeth-
er with it, in the same way as indicated in the automation’s instruction manual.
Dispose of the product packaging material in compliance with established local legis-
lation.
