31
A. Attach the Front Weight Shield (#20) to the Base Frame (#1) and the Guide Rod Retainer (#14) using four
Hex Head Cap Screws 1/4-20 X 3/4 (#48), and four Flat Washers USS 1/4” (#45).
B. Attach the Rear Weight Shield (#19) to the Rear Frame (#5) using four Hex Head Cap Screws 1/4-20 X 3/4
(#48), and four Flat Washers USS 1/4” (#45).
ACS-100 Free Movement Adjustable Cable System
Step 15 Weight Shields Assembly
Assembly List
Item # Description Qty.
19 WEIGHT SHIELD REAR 1
20 WEIGHT SHIELD FRONT 1
40 EDGE PROTECTOR BLACK 1/16 4
45 FLAT WASHER USS B/O 1/4” 8
48 HEX HEAD CAP SCREW GR-5 B/O 1/4-20 X 3/4 8
