Step 2 Assembling Rear Frame and Bottom Support Pulley Brkt to Base Frame
A. Using a rubber mallet, insert two Plastic End Caps 2 X 3 (#73) onto the tube-ends of the Rear Frame (#5).
B. Assemble Rear Frame (#5) and Bottom Support Pulley Brkt (#18) to Base Frame (#1) using two Hex Head
Cap Screws 3/8-16 X 3 1/4 (#56), four Flat Washers SAE 3/8” (#44), and two Nylon Insert Lock Nuts 3/8-16
(#66).
C. Assemble fi ve Nylon Pulleys 3 1/2 Rd. (#71) to the pulley brackets of the Rear Frame (#5) using hardware
shown.
ACS-100 Free Movement Adjustable Cable System
Assembly List
Item # Description Qty.
5 REAR FRAME 1
18 BOTTOM SUPPORT PULLEY BRKT 1
44 FLAT WASHER SAE B/O 3/8” 14
50 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 3/4 5
56 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 3 1/4 2
66 NYLON INSERT LOCK NUT B/O 3/8-16 2
69 NYLON INSERT JAM LOCK NUT B/O 3/8-16 5
71 NYLON PULLEY 3 1/2 RD, WHITE 5
73 PLASTIC END CAP W/GROOVE 3 X 2 GREY 2
76 PLASTIC INSERT CAP 2” SQ 1
