STEP 14
18
AP-7000 SERIES MULTI PRESS STATION
Assembly List
Item # Description Qty.
5 BACK PAD 1
10 FOOT ROLL (1 X 5 1/2 X 9) 2
11 FOOT ROLL TUBE 1 X 28 3/8 1
20 SEAT PAD 1
66 FLAT WASHER SAE N/P 3/8” 4
69 FLAT WASHER N/P 3/8 ID X 1 1/2 OD X 3/16 2
74 METAL HINGE 2
75 NYLON FLAT WASHER 1 X 1 1/4 X 1/16 2
87 RUBBER BUMPER W/WASHER 3/8 X 1 1/2 1
98 SOCKET SET SCREW ALLOY 1/4-20 X 1/4 1
104 SPLIT LOCK WASHER N/P 3/8” 2
115 BUTTON HEAD SCREW GR-8 N/P 3/8-16 X 1 1/4 7
NOTES:
1. SOME PARTS CUT OUT/NOT SHOWN FOR CLARITY.
