TuffStuff CSM-600 - Page 11

1. The Weight Lift Bar Assembly (*20) has a twist locking mechanism
that allows you to safely lock out the Weight Lift Bar Assembly (*20)
at virtually any setting. See Fig. A
2. If you are adding or storing weight plates on the Weight Prongs of the Press Bar
Housings (#14, #15), do not over-load them. Allow enough space for weight collars.
(Collars must be purchased separately). See Fig. B
3. Pay special attention to the Safety Stoppers Brackets (#18, #19). Be sure they are fully
engaged into the Stopper Prongs (#85) of the Safety Stopper Posts (#12).
Refer to Fig. C for further illustration.
Fig. A Illustration above depicts the Weight Lift
Bar locking mechanism.
Fig. B Warning: Use collars to prevent the weight
plates from falling o the Weight Prongs.
Fig. C Danger: Check that both Safety Stopper
Brackets are fully engaged into the Stopper Prongs.
Safety Precautions
Lock
Unlock
Barbell Weight Plates
Weight Prong
Olympic Bar Collar
11CSM-600 Basic Smith Machine/Half Cage Combo w/Safety Stoppers
www.tuffstuftness.com
