Safety Precautions
Press Bar
Fully Engaged
WRONG
Disengaged
Press Bar
During Exercise
4. DANGER: Once the unit is completely assembled take the time to ensure that the unit is
assembled correctly square and perpendicular. Pay special attention to the Weight Lift
Bar Assembly (*20) making sure both hooks engage uniformly and completely into each
Stopper Prong (#85). If both of the Weight Lift Bar Hooks are not engaging uniformly into the
Stopper Prongs (#85), it will be necessary to loosen some frame hardware then re-align the
frame and re-tighten the hardware. If problem persists, Do Not Use the Machine and contact
your TuStu Retailer or Customer Service (888) 884-8275.
5. The illustrations above depict the Weight Lift Bar Assembly (*20) disengaged setting which is
used during exercise.
6. DANGER: The Safety Stoppers Brackets (#18, #19) prevent the Weight Lift Bar
Assembly (*20) from being lowered below required point and avoid getting crushed under the
Weight Lift Bar Assembly (*20) if the weight is too heavy to control. Ensure that the Safety
Stoppers Brackets (#18, #19) are set to an equal adjustment setting (same height). Before
you add weight plates to the Weight Lift Bar Assembly (*20) you must rst set-up the Safety
Stoppers Brackets (#18, #19) for the required exercise. It is recommended that you test the
desired setting without weight plates on the Weight Lift Bar Assembly (*20) to make sure the
Safety Stoppers Brackets (#18, #19) are set to the appropriate exercise setting.
1
2
Lock
1
2
Unlock
