Proceed to inspect; align and wrench tighten ALL hardware
assemblies specially those left loosely fasten, making sure
the unit is assembled square and perpendicular.
100%
Fully Tighten
Step 12
Note:
It is strongly recommended that two
people participate in this assembly step.
Press Bar
Fully Engaged
WRONG
DANGER: Pay special attention to the Weight Lift Bar Assembly (*20) making sure both hooks
engage uniformly and completely into each Stopper Prong (#85). If both of the Weight Lift Bar
Hooks are not engaging uniformly into the Stopper Prongs (#85), it will be necessary to loosen
some frame hardware then re-align the frame and re-tighten the hardware. If problem persists, Do
Not Use the Machine and contact your TuStu Retailer or Customer Service (888) 884-8275.
25CSM-600 Basic Smith Machine/Half Cage Combo w/Safety Stoppers
