General Description
Sequencer for controlling the pneumatic cleaning function of industrial dust
collection systems. The device has three output relays contacts and two digital
input contacts.
A large, bright display is provided for reading the filter obstruction level, the
active solenoid valves and any alarms in any moment.
Technical Specifications
Casing
Made of insulating, ABS base and polycarbonate lid.
Degree of protection to water and dust: IP65 (EN60529).
Shock resistance: IK07, impact energy 2 Joule (EN62262).
Performance of the Device
Dedicated software program, managed by the microprocessor, easy to set up
and consult, facilitates the use of the instrument also by users unfamiliar.
Led display with 7 segments, 3 digits (0.8” each).
Power voltage 115-230 Vac 50-60 Hz selectable by means of jumpers, must
also set with F05 (Optional 24 Vac/Vdc).
Output voltage 24Vdc, 24-115-230Vac selectable by means of jumper.
Three alarm relays.
Micro SD memory card for data storage, extractable for consultation.
Sampling is performed every 10 seconds, the time interval is editable.
Compressed air presence enable input.
External contact cleaning activation.
Manual solenoid valve activation.
Operating times expressed in seconds with selectable ranges for any
application.
Solenoid valve not working alarm.
Total and partial hour counter for maintenance.
Setting the current date and time associated with the archiving historical
data on the SD card, where are stored the detected values.
