Electric Specifications
Electric Power
115 Vac 50-60 Hz – 25W
230 Vac 50-60 Hz – 25W
24 Vac 50-60 Hz – 25W (optional)
24 Vdc– 25W (optional)
Selectable Output Voltage
230 Vac
115 Vac
24 Vac
24 Vdc
Inputs And Outputs Galvanically Insulated
Enable contact (remote cleaning enable).
Fan contact (post-cleaning).
The solenoid valves connected to the unit are normally closed.
The activation of a solenoid valves causes them to open and consequently let out
a jet of air.
Alarm Relays
The three alarm relays contain 2 clean contacts on terminals 4 ÷ 9 di J4.
Maximum permitted load: 3A @ 250Vac, 2A @ 24Vac, 2A @ 24Vdc
Fuse
1 x 1 A @ 115 Vac. 1 x 1 A @ 230 Vac.
1 x 3 A @ 24 Vac. 1 x 3 A @ 24 Vdc.
Working Temperature
from -10°C to 55°C
Storage Temperature
-20°C to 60°C
Timer Specifications:
Pulse Time (Valve Opening)
from 50 ms to 5 sec
Pause Time (Interval Between Valve Openings)
1 sec - 999 sec
War n i n g ! Read t he sec t i o n on
in s t a l lation b e fore c on n e cting
the d evice.
