List of Functions
F02: Solenoid activation time.
Possible values: 0.05” – 5.00” step 0.01”.
Default = 0.20”.
F03: Washing pause time between solenoid valves.
Possible values: 001” – 999” step 1”.
Default = 20”.
F04: Number of connected outputs.
Possible values: 01 - 99
Depending on the version of the instrument, step 1.
F05: Output voltage setting.
Possible values: d24, A24, 115, 230.
Default = A24.
F06: Manual output activation.
Possible values: 1 – number of outputs set in F04.
Press SET to activate the set output.
F13: Number of post cleaning cycles after stopping the fan.
Possible values: 01 – 99 step 1.
Default = 01.
F14: Post cleaning mode pause time between solenoid valves (fan off).
Possible values: 001” – 999” step 1”.
Default = 10”.
F15: Maintenance frequency expressed in tens of hours.
(e.g.: 1=10h, 10=100h).
Possible values: 001 – 999 step 1.
Default = 100 (=1000h).
F16: Maintenance deadline alarm enable.
Possible values: 0 (disabled) – 1 (enabled).
Default = 0 (disabled).
F17: Maintenance hour counter reset.
Possible values: 0 (disabled) – 1 (reset).
Default = 0 (disabled).
Note: The maintenance hour counter
will be reset and the F17 parameter will be set back to 0 by setting F17 to 1.
F24: Setting the date on the internal clock.
Settable values: Day 1 – 31 d.
Month 1 – 12 п.
Year 00 – 99 y.
F25: Setting of the time for the internal clock.
Settable values: Hours: 0 – 23 HH.
Minutes: 0 – 59 пп.
F26: Exclusion of the valve in short circuit.
If set to 1 the valve shorted is excluded from the cycle.
Settable Values 0 (not excluded) - 1 (excluding)
Default = 0 (not excluded).
