iNSPIRE iP2000/iP1000 Quick Start Guide
17
Technical Specifi cations
iP2000 iP1000
System
Frequency response
45 Hz – 20 kHz ±3 dB
38 Hz – 20 kHz -10 dB
50 Hz – 20 kHz ±3 dB
43 Hz – 20 kHz -10 dB
Nominal dispersion
120° H @ -6 dB points 120° H @ -6 dB points
Maximum SPL
123 dB 122 dB
Crossover type
4 way, active and passive 4 way, active and passive
Transducers
1 x 12" (305 mm) LF driver
16 x 2.75" (70 mm) MF drivers
1 x 1" (25 mm) HF compression driver
2 x 8" (208 mm) LF drivers
8 x 2.75" (70 mm) MF drivers
1 x 1" (25 mm) HF compression driver
Limiter
Independent HF, LF Independent HF, LF
Amplifi er
Maximum output power*
1000 W 1000 W
Type
Class-D Class-D
Protection
Short circuit, open circuit, thermal Short circuit, open circuit, thermal
Amplifi er channels
33
Connectors
Input A / B
2 x combo jack / XLR 2 x combo jack / XLR
Sensitivity 4 dBu, nominal 4 dBu, nominal
Input impedance 16 kΩ unbalanced, 33 kΩ balanced 16 kΩ unbalanced, 33 kΩ balanced
Maximum input level +22 dBu +22 dBu
Link output
XLR XLR
Mains supply
IEC mains connector with integrated
power switch
IEC mains connector with integrated
power switch
Controls
Hardware
Rotary push-encoder Rotary push-encoder
Software
iOS interface via Bluetooth iOS interface via Bluetooth
User DSP Functions
Factory EQ presets
Positioning, sound mode Positioning, sound mode
Display
LCD 128 x 32, blue, backlit LCD 128 x 32, blue, backlit
Equalisation
Bass, middle and treble Bass, middle and treble
Protection
Lock-out function for all settings Lock-out function for all settings
Bluetooth Wireless Technology
Frequency range
2402 MHz ~ 2480 MHz 2402 MHz ~ 2480 MHz
Channel number
79 79
Version
Bluetooth 4.0 dual mode Bluetooth 4.0 dual mode
Output
8 dBM 8 dBM
Compatibility
Supports A2DP 1.2 profi le Supports A2DP 1.2 profi le
Maximum communication range
30 m (without interference) 30 m (without interference)
Connectivity
Master-slave: stereo pairing link Master-slave: stereo pairing link
iP2000 iP1000
Power Supply
Power consumption
110 W @
1
/
8
max power 110 W @
1
/
8
max power
Voltage (fuses)
USA / Canada / Japan 100-120 V~, 50/60 Hz (T 6.3 A H 250 V) 100-120 V~, 50/60 Hz (T 6.3 A H 250 V)
UK / Australia / Europe 220-240 V~, 50/60 Hz (T 3.15 A H 250 V) 220-240 V~, 50/60 Hz (T 3.15 A H 250 V)
Korea / China 220-240 V~, 50/60 Hz (T 3.15 A H 250 V) 220-240 V~, 50/60 Hz (T 3.15 A H 250 V)
Enclosure
Dimensions (HWD)
2063 x 420 x 500 mm (81.2 x 16.5 x 19.7") 1955 x 262 x 370 mm (77.0 x 10.3 x 14.6")
Base
485 x 420 x 500 mm (19.1 x 16.5 x 19.7") 655 x 262 x 370 mm (25.8 x 10.3 x 14.6")
Tower
834 x 103 x 89 mm (32.8 x 4.0 x 3.5") 1345 x 103 x 89 mm (53.0 x 4.0 x 3.5")
Net weight
30.9 kg (68.1 lbs) 24.8 kg (54.7 lbs)
Construction, base
15 mm (
5
/
8
") birch plywood 15 mm (
5
/
8
") birch plywood
Construction, tower
Aluminium alloy Aluminium alloy
Finish
Semi matt black paint Semi matt black paint
Grille
Powder coated perforated steel Powder coated perforated steel
Accessories
––
*independent of limiters and driver protection circuits
†Only qualifi ed personnel are allowed to modify the AC-Main cord and to adhere to all applicable national standards.
