Technical Speci cations
iP2000 iP1000 iP500
System
Frequency response
45 Hz – 20 kHz ±3 dB
38 Hz – 20 kHz -10 dB
50 Hz – 20 kHz ±3 dB
43 Hz – 20 kHz -10 dB
65 Hz – 14 kHz ±3 dB
50 Hz – 16 kHz -10 dB
Nominal dispersion 120° H @ -6 dB points 120° H @ -6 dB points 100° H @ -6 dB points
Maximum SPL 123 dB 122 dB 118 dB
Crossover type 4 way, active and passive 4 way, active and passive 2 way, active
Transducers
1 x 12" (305 mm) LF driver
16 x 2.75" (70 mm) MF drivers
1 x 1" (25 mm) HF compression driver
2 x 8" (208 mm) LF drivers
8 x 2.75" (70 mm) MF drivers
1 x 1" (25 mm) HF compression driver
1 x 8" (208 mm) LF driver
6 x 2" (54.2 mm) HF drivers
Limiter Independent HF, LF Independent HF, LF Independent HF, LF
Ampli er
Maximum output power* 1000 W 1000 W 600 W
Type Class-D Class-D
LF: Class-D
HF: Class AB
Protection Short circuit, open circuit, thermal Short circuit, open circuit, thermal Short circuit, open circuit, thermal
Ampli er channels 332
Connectors
Input A / B 2 x combo jack / XLR 2 x combo jack / XLR 2 x combo jack / XLR
Sensitivity 4 dBu, nominal 4 dBu, nominal 4 dBu
Input impedance 16 k unbalanced, 33 k balanced 16 k unbalanced, 33 k balanced 16 k unbalanced, 33 k balanced
Maximum input level +22 dBu +22 dBu +22 dBu
Link output XLR XLR XLR
Mains supply IEC mains connector with integrated powerswitch
† IEC mains connector with integrated powerswitch† IEC mains connector with integrated power switch†
Controls
Hardware Rotary push-encoder Rotary push-encoder Rotary push-encoder
Software iOS interface via Bluetooth iOS interface via Bluetooth iOS interface via Bluetooth
User DSP Functions
Factory EQ presets Positioning, sound mode Positioning, sound mode Positioning, sound mode
Display LCD 128 x 32, blue, backlit LCD 128 x 32, blue, backlit LCD 128 x 32, blue, backlit
Equalisation Bass, middle and treble Bass, middle and treble Bass, middle and treble
Protection Lock-out function for all settings Lock-out function for all settings Lock-out function for all settings
Bluetooth Wireless Technology
Frequency range 2402 MHz ~ 2480 MHz 2402 MHz ~ 2480 MHz 2402 MHz ~ 2480 MHz
Channel number 79 79 79
Version Bluetooth 4.0 dual mode Bluetooth 4.0 dual mode Bluetooth 4.0 dual mode
Output 8 dBM 8 dBM 8 dBm
Compatibility Supports A2DP 1.2 pro le Supports A2DP 1.2 pro le Supports A2DP 1.2 pro le
Maximum communication range 30 m (without interference) 30 m (without interference) 30 m (without interference)
Connectivity Master-slave: stereo pairing link Master-slave: stereo pairing link Master-slave: stereo pairing link
iP2000 iP1000 iP500
Power Supply
Power consumption 110 W @

⁄

max power 110 W @

⁄

max power 80 W @

⁄

max power
Voltage (fuses)
USA / Canada / Japan 100-120 V~, 50/60 Hz (T 6.3 A H 250 V) 100-120 V~, 50/60 Hz (T 6.3 A H 250 V) 100-120 V~, 50/60 Hz (T 6.3 A H 250 V)
UK / Australia / Europe 220-240 V~, 50/60 Hz (T 3.15 A H 250 V) 220-240 V~, 50/60 Hz (T 3.15 A H 250 V) 220-240 V~, 50/60 Hz (T 3.15 A H 250 V)
Korea / China 220-240 V~, 50/60 Hz (T 3.15 A H 250 V) 220-240 V~, 50/60 Hz (T 3.15 A H 250 V) 220-240 V~, 50/60 Hz (T 3.15 A H 250 V)
Enclosure
Dimensions (H x W x D) 2063 x 420x 500 mm (81.2 x 16.5 x 19.7") 1955 x 262 x 370 mm (77.0 x 10.3 x 14.6") 2006 x 321 x 400 mm (79.0 x12.6 x 15.7")
Base 485 x 420 x 500 mm (19.1x 16.5 x 19.7") 655 x 262 x 370 mm (25.8 x 10.3 x 14.6") 416 x 321 x 400 mm (16.4x 12.6 x 15.7")
Tower 834 x 103 x 89 mm (32.8x 4.0 x 3.5") 1345 x 103 x 89 mm (53.0 x 4.0 x 3.5") 918 x 132 x 72 mm(36.1 x 5.2 x 2.8")
Net weight 30.9 kg (68.1 lbs) 24.8 kg (54.7 lbs) 15.1 kg (33.2 lbs)
Construction, base 15 mm (

⁄

") birch plywood 15 mm (

⁄

") birch plywood Engineering plastic (GXPP)
Construction, tower Aluminium alloy Aluminium alloy Engineering plastic (ABS)
Finish Semi matt black paint Semi matt black paint Semi matt black paint
Grille Powder coated perforated steel Powder coated perforated steel Powder coated perforated steel
Accessories
– – Protective cover (included)
*independent of limiters and driver protection circuits
†Only quali ed personnel are allowed to modify the AC-Main cord and to adhere to all applicable national standards.

Turbosound iNSPIRE iP2000 Specifications

General

Amplifier Type	Class-D
Max SPL	126 dB
Woofer	1 x 12"
Outputs	1 x XLR
Bluetooth	Yes
Mixer	3-channel digital mixer
Power Output	2000 W
Enclosure Material	Aluminum
Tweeter	16 x 2.75"
Dispersion	120° H
