Turbosound iNSPIRE User Manual

16 iNSPIRE iP82/iP15B/iP12B Quick Start Guide 17
Main Page (1 speaker) Main Page (2 speakers linked) Settings Page
IMPORTANT NOTE: The mounting of a permanently installed sound system may be dangerous unless undertaken by qualied personnel with the required experience and
certication to perform the necessary tasks. Walls, oors or ceilings must be capable of safely and securely supporting the actual load. Themounting accessory used must be
safely and securely xed both to the loudspeaker and to the wall, oor or ceiling.
When mounting rigging components on walls, oors or ceilings, ensure that all xings and fasteners used are of an appropriate size and load rating. Wall and ceiling
claddings, and the construction and composition of walls and ceilings, all need to be taken into account when determining whether a particular xing arrangement can be
safely employed for a particular load. Cavity plugs or other specialist xings, if required, must be of an appropriate type, and must be tted and used in accordance with the
maker’sinstructions.
The operation of your speaker cabinet as part of a own system, if installed incorrectly and improperly, canpotentially expose persons to serious health risks and
even death. In addition, please ensure that electrical, mechanical and acoustic considerations are discussed with qualied and certied (by local state or national
authorities) personnel prior to any installation or ying.
Make sure that speaker cabinets are set up and own by qualied and certied personnel only, usingdedicated equipment and original parts and components
delivered with the unit. If any parts or components are missing please contact your Dealer before attempting to set up the system.
Be sure to observe the local, state and other safety regulations applicable in your country. Music Tribe, including the Music Tribe companies listed on the enclosed
“Service Information Sheet”, assumes no liability for any damage or personal injury resulting from improper use, installation or operation of the product.
Regular checks must be conducted by qualied personnel to ensure that the system remains in a secure and stable condition. Make sure that, where the speaker is
own, the area underneath the speaker is free of human trac. Do not y the speaker in areas that can be entered or used by members of the public.
Speakers create a magnetic eld, even if not in operation. Therefore, please keep all materials that can be aected by such elds (discs, computers, monitors, etc) at a
safe distance. A safe distance is usually between 1 and 2 metres.
Gracias por elegir un producto de altavoz Turbosound para su aplicación. Si desea obtener más información sobre este o cualquier otro producto Turbosound, visite
nuestro sitio web en turbosound.com.
Desembalaje del altavoz
Después de desembalar la unidad, compruebe cuidadosamente si hay daños. Si encuentra daños, notique a su proveedor de inmediato. Usted, el destinatario, debe
iniciar cualquier reclamación. Conserve todo el embalaje en caso de reenvío futuro.
Controls
(1) PERILLA CODIFICADOR alterna entre los modos Gráco y Edición (cuando se presiona) y cambia los valores de los parámetros (cuando se gira).
(2) PANTALLA LCD muestra el módulo DSP actual y la conguración de los parámetros.
(3) PROCESO El botón accede al menú de procesamiento de la señal DSP.
(4) CONFIGURACIÓN El botón accede al menú de funciones de conguración.
(5) SALIDA El botón guarda los cambios y regresa a la pantalla del menú anterior.
(6) INGRESAR El botón selecciona el submenú o conrma los cambios de parámetros.
(7) ENTRADA A / ENTRADA B Las tomas combo aceptan señales de entrada usando conectores XLR, TRS balanceados de ¼ "o TS de ¼" no balanceados.
(8) ENLACE A / ENLACE B Los conectores XLR proporcionan copias sin procesar de las señales INPUT A o INPUT B.
(9) SALIDA A / SALIDA B ofrece conexiones compatibles con Neutrik SpeakON para impulsar gabinetes de altavoces pasivos adicionales.
(10) APORTE en el panel iP82 acepta conexiones de amplicador de potencia mediante conectores compatibles con Neutrik SpeakON.
(1)
(2)
(3)
(7)
(4)
(6)
(5)
(8)
(9)
(10)

Turbosound iNSPIRE Specifications

General

Type	Powered subwoofer
Inputs	2 x combo jack/XLR
Outputs	XLR
Enclosure Material	Plywood
Input Connectors	2 x combo jack/XLR
Output Connectors	XLR
