Turbosound iX15 User Manual

48 iX Series Quick Start Guide 49
Specications
iX15 iX12
System
Frequency response
45 Hz – 20 kHz ±3 dB
39 Hz – 20 kHz -10 dB
50 Hz – 20 kHz ±3 dB
42 Hz – 20 kHz -10 dB
Nominal dispersion 75° H x 55° V @ -6 dB points 80° H x 60° V @ -6 dB points
Maximum SPL 126 dB 125 dB
Crossover type Active Active
Transducers
1 x 15" (387 mm) LF driver
1 x 1" (25.4 mm) HF compression driver
1 x 12" (308.5 mm) LF driver
1 x 1" (25.4 mm) HF compression driver
Limiter Independent HF, LF Independent HF, LF
Amplier
Maximum output power* 1000 W 1000 W
Type LF: Class-D, HF: Class AB LF: Class-D, HF: Class AB
Protection Short circuit, open circuit, thermal Short circuit, open circuit, thermal
Connectors
Input A / B 2 x combo jack / XLR 2 x combo jack / XLR
Sensitivity for max out with
volume control at 0dB
+4 dBu +4 dBu
Input impedance 16 k unbalanced, 33 k balanced 16 k unbalanced, 33 k balanced
Maximum input level +22 dBu +22 dBu
Output XLR, servo-balanced XLR, servo-balanced
Output impedance 220  unbalanced, 600  balanced 220  unbalanced, 600  balanced
Mains Supply
IEC mains connector with integrated powerswitch IEC mains connector with integrated powerswitch
Controls
Hardware
Rotary push-encoder Rotary push-encoder
Software
iOS interface via Bluetooth iOS interface via Bluetooth
User DSP Functions
Factory EQ presets
Positioning, Sound mode, Phase Positioning, Sound mode, Phase
Display
LCD 128 x 32, blue, backlit LCD 128 x 32, blue, backlit
Equalisation
Bass and treble controls Bass and treble controls
Crossover
High pass L-R 24 dB/oct High pass L-R 24 dB/oct
Protection
Lock-out function for all settings Lock-out function for all settings
Bluetooth Wireless Technology
Frequency range
2402 MHz ~ 2480 MHz 2402 MHz ~ 2480 MHz
Channel number
79 79
Version
Bluetooth 4.0 dual mode Bluetooth 4.0 dual mode
Output
8 dBM 8 dBM
Compatibility
Supports A2DP 1.2 prole, BLE Supports A2DP 1.2 prole, BLE
Maximum communication range
35 m (without interference) 35 m (without interference)
Connectivity
Master-slave: stereo pairing link Master-slave: stereo pairing link
iX15 iX12
Power Supply
Power consumption 80 W @

⁄

max power 80 W @

⁄

max power
Voltage
USA / Canada 120 V~, 60 Hz 120 V~, 60 Hz
UK / Australia / Europe 220-240 V~, 50/60 Hz 220-240 V~, 50/60 Hz
Korea / China 220-240 V~, 50/60 Hz 220-240 V~, 50/60 Hz
Japan 100 V~, 50/60 Hz 100 V~, 50/60 Hz
Enclosure
Dimensions (HWD) 711 x 450 x 381 mm (27.9 x 17.7 x 15.0") 609 x 370 x 370 mm (24.0 x 14.5 x 14.5")
Net weight 22.4 kg (49.4 lbs) 19.4kg (42.8 lbs)
Construction Injection-moulded polypropylene enclosure Injection-moulded polypropylene enclosure
Finish Black paint Black paint
Grille Powder coated perforated steel Powder coated perforated steel
Flying hardware – –
Accessories
– –
*independent of limiters and driver protection circuits
†Only qualied personnel are allowed to modify the AC-Main cord and to adhere to all applicable national standards.
