Operation
14
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
To transfer data from the FIFO memory of the interface to the controller, execute the
Read data from the buffer (0x0011) command. In addition to the read data, the address
of the read/write head that is being used is also transferred. The length of the data avail-
able in the FIFO memory is displayed in the input data under Data (bytes) available
(BYFI). The length of the data must be consistent. Example: If the UID, reserved byte and
read/write head address for each tag are being written to the FIFO memory, at least
10bytes of data must be read from the buffer.
NOTE
Data in the FIFO memory is not overwritten until it has been transferred to the con-
troller. New readings are stored in the FIFO memory.
To end Continuous mode, execute the End Continuous mode (0x0012) command.
or
To end Continuous mode and clear the FIFO memory of the interface, send the Reset
(0x0800) command.
NOTE
The data must be transferred from the device to the higher level on a regular basis. If
the 16-KB ring buffer is full, no further data can be saved and the device displays an
error message.
User data areas for the HF tag
Chip type User data area Access Bytes per block
First block Last block Total memory
[byte]
NXP SL2 SLI 0x00 0x1B 112 read/write 4
NXP SL2 SLI-S 0x00 0x27 160 read/write 4
NXP SL2 SLI-L 0x00 0x07 32 read/write 4
Fujitsu
MB89R118
Fujitsu
MB89R118B
0x00 0xF9 2000 read/write 8
Fujitsu
MB89R112
0x00 0xFF 8192 read/write 32
TI Tag-it HFI Plus 0x00 0x3F 256 read/write 4
TI Tag-it HFI 0x00 0x07 32 read/write 4
Infineon SR-
F55V02P
0x00 0x37 224 read/write 4
Infineon SR-
F55V10P
0x00 0xF7 992 read/write 4
EM4233 0x00 0x33 208 read/write 4
EM4233 SLIC 0x00 0x1F 128 read/write 4
