TURING Vision Quick Start Guide – Smart Series Hardware Setup
4
Connect Power to Monitor and Bridge
Monitor
Power
Bridge Box
Network PortPorts HDMI
LAN USB HDMI
NVR
Router/Switch
Power
Ethernet
Ethernet
Ethernet
LAN1 LAN2/WAN
