Turnstone Campfire - Big Table with Trough Assembly

Page 3 of 10
939500545 Rev D
1
6x
2
4x
2x
Big Table with Trough
Apply stickers on all visible cam joint faces
to cover the connector faces, after assembly.
(LPL and HPL only).
Cam Lock Fastening
(The cam lock screw needs
to be turned 3/4 full turn or
270
o
for complete engagement.)
