Turnstone Campfire - Big Table with Power Assembly

Page 6 of 10
939500545 Rev D
2
Big Table with Power
1
6x
4x
4x
12x
3
Cam Lock Fastening
(The cam lock screw needs
to be turned 3/4 full turn or
270
o
for complete engagement.)
Apply stickers on all
visible cam joint faces
to cover the connector
faces, after assembly
(LPL and HPL only).
Optional Mobile Cabinet
Stop Brackets
