TUYA BLE PRO - Page 9

15
16
5.2 Hanging Garment
h
5.2 .1 Unplug
Rubber plug
f
5.2 .2 Battery mounting
Put 4pcs AAA alkaline batteries
and fix the battery box cover.
5.2.3 Shackle Locking
-knob
Buckle the shackle and lock
box in the direction of the
arrow.
5.2.4 Shackle unlock
-knob
Unhook
button
Push the button to the top,
then detach the lock box and shackle.
You need to
push up hard
to unhook
