Tview T700SVD - Device Controls and Specifications; Control Panel Overview; Remote Control Functions; Performance Parameters

Performance parameter
Inset to LCD S terminal
Type:TFT LCD
Display size: 7"
Display format: 16:9
Power: About 7W
Power supply: DC 12V
System: NTSC/PAL
Operation temperature:+5 ~+40
Pixel:480(W) R/G/B 234(H)=336960
Overall dimension:385(W) 148(L) 23(H)mm
Weight:about 780g
2 AV inputs
Fuse 2A
Black to grounding
Red to battery +12V
Left audio input (white)
1st video input (yellow)
Method of wiring
Power switch
V1/V2
Decrease
Increase
Turn image
MENU
VIDEO
SELECT
MODE
SELECT
VIDEO
SELECT
MENU
MODE
SELECT
Menu
Right audio input(red)
TFT LCD
TFT LCD
REMOTE
WINDOW
POWER
SWITCH
MENU
V1/V2
TURN
Audio input (black)
2nd video input (yellow)
MUTE
