102
DESCRIPTION TVS APACHE RTR 160 4V
ELECTRICAL
Tail / brake lamp LED lamps (1W max / 2.5W max)
Turn signal lamp 12V,10W x 4
Number plate lamp 12V, 5W x 1
Instrument panel LCD / LED indicators
Horn 12V, DC x 2
Fuse
Main 12V, 25A x 1
ABS 12V, 15A x 1
Load 12V, 15A x 1
EMS 12V, 10A x 1
Using the bulb other than the specified rating can result in overloading of the electrical system or premature failure of the
bulb.
